OEM Aluminum Investment Casting Services with Pressurized Die Mold Making

OEM aluminum investment casting services integrated with pressurized die mold making represent the pinnacle of precision manufacturing for complex aluminum components. This advanced manufacturing approach combines the dimensional accuracy of investment casting with the efficiency of pressurized die technology, delivering superior aluminum parts with exceptional surface finish and mechanical properties for demanding industrial applications.

Material Excellence and Performance Characteristics

Our services utilize premium aluminum alloys including A356, A357, and 356-T6, specifically engineered for investment casting applications. These materials deliver outstanding performance characteristics:

• A356-T6: Tensile strength 234-262 MPa, yield strength 164-193 MPa, elongation 3-5%

• 356-T6: Tensile strength 255 MPa minimum, yield strength 207 MPa, Brinell hardness 75

• Excellent corrosion resistance with natural oxide layer formation

• Thermal conductivity: 120-160 W/m·K for efficient heat dissipation

• Low density (2.68 g/cm³) providing significant weight reduction advantages

The controlled silicon content (6.5-7.5%) in these alloys ensures optimal fluidity during the pressurized casting process while maintaining excellent mechanical properties after T6 heat treatment.

Advanced Manufacturing Process Integration

Our integrated manufacturing process combines traditional investment casting with innovative pressurized die technology:

Pressurized Die Mold Making:

• High-precision mold manufacturing using CNC machining centers

• Pressure-controlled wax injection systems (5-15 bar)

• Temperature-regulated die plates maintaining ±2°C accuracy

• Multi-cavity mold designs for production efficiency

Investment Casting Process:

• Ceramic shell building with zircon-based primary coatings

• Controlled dewaxing using high-pressure steam autoclaves

• Pressure-assisted pouring at 1.5-3.0 bar for complete mold filling

• Directional solidification technology for optimized microstructure

Heat Treatment and Finishing:

• Solution treatment at 540°C ± 5°C for 8-10 hours

• Quenching in hot water (65-80°C) to minimize distortion

• Artificial aging at 155-165°C for 4-6 hours

• CNC machining to achieve final dimensional requirements

Quality Assurance and Technical Specifications

Each component undergoes comprehensive quality validation:

• Dimensional accuracy: CT4-6 per ISO 8062 standards

• Surface finish: Ra 1.6-3.2 μm in as-cast condition

• X-ray inspection for internal integrity verification

• Mechanical property testing per ASTM standards

• Leak testing for pressure-critical applications

• First article inspection with full dimensional reporting

Technical Advantages and Performance Benefits

The integration of pressurized die technology with investment casting delivers significant advantages:

• Reduced porosity levels below 1% through pressure-assisted solidification

• Improved yield strength through controlled cooling rates

• Enhanced surface finish minimizing post-casting processing

• Complex internal features achievable without cores

• Consistent dimensional stability across production batches

• Reduced machining allowances saving material costs

Industry Applications and OEM Solutions

Our aluminum investment casting services support diverse OEM requirements:

Aerospace and Defense:

• Structural components and brackets

• Engine and turbine components

• Avionics housings and mounts

Automotive and Transportation:

• Engine components and intake manifolds

• Transmission and drivetrain parts

• Suspension and braking components

Industrial and Commercial:

• Pump and valve bodies

• Hydraulic system components

• Machinery and equipment parts

Medical and Dental:

• Equipment housings and frames

• Surgical instrument components

• Diagnostic equipment parts

The combination of pressurized die mold making with aluminum investment casting creates an optimal manufacturing solution for OEMs requiring high-precision, complex aluminum components with superior mechanical properties and dimensional accuracy. Our integrated approach ensures consistent quality, reliable performance, and cost-effective manufacturing for both prototype and production quantities, making it the preferred choice for demanding applications across multiple industries.
