High Quality Casting Services for Oilfield Well Drilling Pump Housing Product

Robust Engineering for Demanding Oilfield Applications
Our specialized casting services deliver premium-quality pump housings specifically engineered for the extreme demands of oilfield well drilling operations. These critical components are manufactured to withstand high-pressure cycling, abrasive drilling fluids, and continuous operation in the world's most challenging drilling environments, ensuring reliability when performance matters most.

Advanced Material Technology
We employ high-strength alloy steels and specialized irons developed for oilfield service:

• ASTM A487 Grade 4N: High-strength low-alloy steel with superior yield strength (550-750 MPa)

• Ductile Iron 80-55-06: Delivering optimal strength-to-weight ratio with excellent impact resistance

• Stainless Steel CF8M: Providing exceptional corrosion resistance in sour gas environments

• White Iron Ni-Hard 4: Offering maximum abrasion resistance for slurry service
  All materials include full traceability and certification to API 6A/ISO 11960 standards, with Charpy V-notch testing at -40°C for arctic applications.

Enhanced Performance Characteristics

• Pressure Integrity: Hydrostatically tested to 1.5 times maximum working pressure (typically 5,000-15,000 PSI)

• Abrasion Resistance: Hardness ratings of 400-600 BHN for extended service life in abrasive mud service

• Corrosion Performance: Certified for sour service per NACE MR0175/ISO 15156 requirements

• Fatigue Strength: Engineered to withstand minimum 10^7 pressure cycles at maximum operating conditions

• Dimensional Stability: Maintains critical tolerances across temperature ranges from -50°C to 150°C

Precision Manufacturing Process
Our integrated manufacturing system ensures uncompromising quality:

Pattern & Mold Engineering

• CAD/CAM designed patterns with pressure containment optimization

• Resin sand molding systems for dimensional accuracy within CT9 per ISO 8062

• Controlled mold hardness maintaining 85-95 throughout production

Casting Excellence

• Vacuum degassed steel ensuring minimal gas porosity

• Computer-controlled pouring with ±10°C temperature accuracy

• Real-time solidification monitoring using thermal analysis

Heat Treatment & Machining

• Normalizing and tempering for optimized mechanical properties

• CNC machining maintaining bore concentricity within 0.025mm

• Precision thread machining to API 7-1 specifications

Quality Assurance Protocol

• 100% radiographic examination per ASTM E94 standards

• Ultrasonic testing for internal integrity verification

• Magnetic particle inspection of all critical surfaces

• Pressure testing to API 6A requirements with full documentation

• Material certification including full chemical and mechanical properties

Technical Specifications

• Pressure ratings: 5,000 PSI to 15,000 PSI working pressure

• Size range: 6-inch to 12-inch fluid end housings

• Weight capacity: 200kg to 2,000kg

• Surface finish: Ra 3.2μm on critical bore surfaces

• Delivery lead time: 8-12 weeks for standard configurations

Industry Compliance

• API 6A/ISO 10423 certification

• API Q1 quality management system

• NACE MR0175 for sour service applications

• ISO 9001:2015 quality management

• CE/PED certification for European markets

Competitive Advantages

• 40+ years oilfield component manufacturing experience

• Complete in-house metallurgical laboratory

• Engineering support for custom hydraulic designs

• Global supply chain management

• Field-proven performance in extreme drilling conditions

Our oilfield pump housings represent the culmination of advanced metallurgical engineering and precision manufacturing, delivering components that ensure operational reliability in the most demanding drilling applications. The combination of rigorous quality control, material excellence, and manufacturing expertise provides drilling operators with pump housings that maximize service life while minimizing downtime in critical drilling operations.
