Cast Iron Submersible Pump Body Premium Casting Services Product

Engineered for Demanding Submersible Applications
Our premium cast iron submersible pump bodies represent the pinnacle of corrosion-resistant, high-strength casting technology. Specifically engineered for continuous submerged operation, these components deliver unmatched reliability in water supply, wastewater management, and industrial pumping applications where failure is not an option.

Superior Material Engineering
We utilize advanced cast iron grades optimized for submersible environments:

• Ductile Iron EN-GJS-500-7: Delivering exceptional tensile strength (500 MPa) and elongation (7%) for shock resistance

• Austempered Ductile Iron (ADI): Providing superior wear resistance and fatigue strength

• Ni-Resist Cast Iron: Offering enhanced corrosion resistance in saline and chemical environments
  All materials feature controlled graphite formation ensuring optimal pressure containment and corrosion performance, with full certification to ISO 1083/JS/500/7 standards.

Advanced Performance Characteristics

• Corrosion Resistance: Withstands pH ranges from 6.5 to 10.0 with specialized coatings available for extreme conditions

• Pressure Integrity: Hydrostatically tested to 1.5 times maximum working pressure (typically 10-25 bar)

• Cavitation Resistance: Superior material density minimizes surface erosion in high-velocity applications

• Thermal Stability: Maintains dimensional integrity across 0-80°C operational range

• Fatigue Strength: Endures continuous operation exceeding 20,000 hours under design conditions

Precision Manufacturing Process
Our integrated production system ensures exceptional quality:

Pattern Development

• CNC-machined patterns with corrosion allowance optimization

• 3D printed rapid prototypes for design validation

• Modular pattern systems for custom volute configurations

Molding Technology

• Resin sand molding ensuring surface finish Ra 12.5-25μm

• Controlled mold hardness (85-90 scale units)

• Precision core assembly for complex internal waterways

Casting Excellence

• Computer-controlled pouring systems

• In-mold inoculation for consistent microstructure

• Real-time thermal monitoring during solidification

Quality Assurance Protocol

• 100% pressure testing per ISO 9905 requirements

• Ultrasonic thickness verification

• Dimensional inspection using laser scanning

• Material certification including Charpy impact testing

• Coating thickness verification for corrosion protection

Technical Specifications

• Size range: 50mm to 600mm discharge diameters

• Pressure rating: Standard 10 bar, High-pressure 25 bar

• Weight capacity: 5kg to 200kg

• Standard compliance: ISO 5199, ISO 9905

• Surface treatment: Interior epoxy coating available

Industry Applications

• Deep well water extraction systems

• Municipal wastewater treatment plants

• Industrial process water circulation

• Marine and offshore pumping operations

• Mining dewatering and slurry handling

Competitive Advantages

• 30+ years submersible pump component specialization

• Complete in-house design and engineering support

• Custom volute design for optimized hydraulic efficiency

• Short lead times through standardized pattern systems

• Global certification and approval documentation

Our cast iron submersible pump bodies combine advanced metallurgy with precision manufacturing to deliver components that withstand the most challenging submerged applications. The optimized material selection and rigorous quality control ensure reliable performance, extended service life, and reduced total cost of ownership for pump manufacturers and end-users worldwide.
