Deep Hole Drilling CNC Service for Hydraulic Cylinder Barrel Castings

Precision deep hole drilling is a critical manufacturing process for hydraulic cylinder barrel castings, where dimensional accuracy and surface finish directly impact performance and longevity. Our specialized CNC deep hole drilling services deliver exceptional quality for hydraulic applications across various industries.

Material Expertise
We work with high-grade materials essential for hydraulic cylinder performance, including:

• Carbon steels (1045, 4130, 4140)

• Alloy steels

• Stainless steel grades
  These materials are selected for their excellent mechanical properties, wear resistance, and ability to withstand high pressure cycling.

Advanced Manufacturing Process
Our deep hole drilling process utilizes state-of-the-art CNC equipment and gun drilling technology to achieve:

• Bore diameters from 3mm to 200mm

• Depth-to-diameter ratios up to 60:1

• Exceptional straightness accuracy (0.5mm per meter)

• Superior surface finishes (Ra 0.4-1.6 μm)
  The process incorporates high-pressure coolant systems that ensure efficient chip evacuation and maintain tight tolerances throughout the drilling operation.

Performance Characteristics
Hydraulic cylinder barrels manufactured using our deep hole drilling services provide:

• Excellent dimensional stability under high pressure

• Superior surface integrity for enhanced seal life

• Optimal geometric accuracy for smooth piston movement

• Improved fatigue resistance and service life

Industry Applications
Our services support numerous sectors including:

• Construction and mining equipment

• Industrial machinery and automation systems

• Agricultural equipment

• Marine and offshore applications

• Aerospace and defense systems

Quality Assurance
Every component undergoes rigorous inspection, including:

• Dimensional verification

• Surface finish analysis

• Straightness measurement

• Pressure testing validation

With our specialized deep hole drilling capabilities, we deliver hydraulic cylinder barrels that meet the most demanding performance requirements, ensuring reliability and longevity in critical applications.
